Instruction book Audi R8 Version year 2015
Audi R8 Coupé Infotainment Audi connect Setting up
Applies to: vehicles with Audi connect
Fig. 106 Is your mobile phone rSAP enabled? This QR code takes you directly to the mobile device database (data connection costs vary according to your mobile phone contract).
Fig. 106 Is your mobile phone rSAP enabled? This QR code takes you directly to the mobile device database (data connection costs vary according to your mobile phone contract).
Important
Your mobile phone must support the Bluetooth remote SIM Access Profile (Bluetooth rSAP).
For information regarding which Bluetooth connections and functions your mobile phone supports, contact your mobile network service provider or consult the mobile device database at www.audi.com/bluetooth Fig. 106.
The vehicle must be stationary, and the ignition must be switched on.
The Bluetooth function and the discoverability option of the MMI system and the mobile phone must be activated.
The mobile phone you would like to connect must not be connected actively to any other Bluetooth device. The MMI must not be connected to a mobile phone.
Access to your SIM card (SIM Access) must be activated on your mobile phone.1)
Connecting a mobile phone
Select: MENU button > Telephone > Connect mobile phone > Continue. The available Bluetooth devices will be shown on the infotainment display. Or: Search for the MMI system via the Bluetooth device search function on your mobile phone.
Select and confirm the desired mobile phone from the list of Bluetooth devices shown.
Enter the PIN to establish a connection on your mobile phone. Or: If the PIN is already being displayed on your mobile phone, confirm it on the phone and on the MMI. You have about 30 seconds to enter the PIN.
If you wish to connect your mobile phone via the remote SIM Access Profile, please also enter your SIM card s PIN in the MMI1).
Please note any additional system queries on your mobile phone, e.g. whether the phone should connect automatically in the future. On some mobile phones, you may also need to download the directory separately.
Confirm the system query of whether an Internet connection should be established with Accept.
After connecting successfully
The Bluetooth symbol -13-, signal strength symbol -4- and type of connection -3- link will appear in the infotainment display when the mobile phone has been connected successfully.
You can now use Audi connect.
Note
  • Bluetooth devices only have to be bonded once. Depending on the mobile phone you are using, any devices that have already been bonded to the MMI system are connected automatically when they are within range and the ignition is on.
  • You receive the SIM PIN and the PUK from your mobile network service provider together with the SIM card. If you enter the SIM PIN code incorrectly three times2) in a row, the SIM card will be be blocked. A PUK (personal unblocking key) must be entered in order to reactivate the SIM card.
  • The Bluetooth connection between the system and the mobile phone is automatically terminated when you leave the car.
  • For further information regarding your mobile phone, contact your mobile network service provider or refer to the operating instructions for your mobile phone. For information on using a phone in your car, please go online (e.g. www.audi.com/bluetooth) or ask an Audi dealer.
