Applies to: Audi Q7s with Audi connect (infotainment) and Audi phone box
- Fig. 225 Is your mobile phone rSAP enabled? This QR code takes you directly to the mobile device database (data connection costs vary according to your mobile phone contract).
Important1)
Your mobile phone must support the Bluetooth remote SIM Access Profile (Bluetooth rSAP).
For information regarding which Bluetooth connections and functions your mobile phone supports, contact your mobile network service provider or consult the mobile device database at www.audi.com/bluetooth Fig. 225►.
The Audi Q7 must be stationary, and the ignition must be switched on.
The Bluetooth function and the discoverability option of the MMI system link► must be activated.
The Bluetooth function and the discoverability option of the mobile phone must be activated.
The mobile phone you would like to connect must not be connected actively to any other Bluetooth device. The MMI must not be connected to a mobile phone.
Access to your SIM card (SIM Access) must be activated on your mobile phone.
Connecting a mobile phone
Select: MENU button > Audi connect.
Select and confirm Activate data connection.
Select and confirm Connect mobile phone > Continue.
Select and confirm the desired mobile phone from the list of Bluetooth devices shown. Or: Search for the MMI system via the Bluetooth device search function on your mobile phone.
Enter the PIN to establish a connection on your mobile phone. If the PIN is already being displayed on your mobile phone, confirm it on the phone and the MMI. You have about 30 seconds to enter the PIN.
Please note any additional system queries on your mobile phone, e.g. whether the phone should connect automatically in the future. On some mobile phones, you may also need to download the directory separately.
You can now enter the PIN code for your SIM card on the MMI.
To allow the MMI to connect automatically in the future, select and confirm Yes.
After connecting successfully
After the connection has been established successfully, you will be shown a short message containing information on the profiles used to establish the connection. You can make changes to the profiles via MENU > Settings > left control button > MMI settings > Connection manager link►. This can also be done at a later time.
The signal strength symbol -10- and the Bluetooth symbol -16- Fig. ► will appear in the status line of the infotainment display when the mobile phone has been connected successfully.
Confirm the system query of whether an Internet connection should be established with Yes, always connect if necessary.
You can now use Audi connect (infotainment) services.
Note
- It is only possible to connect a mobile phone via the remote SIM Access Profile on Audi Q7s with the Audi phone box.
- Bluetooth devices only have to be bonded once. Depending on the mobile phone you are using, any devices that have already been bonded to the MMI system are connected automatically when they are within range and the ignition is on. You can bond several mobile phones to the MMI system; however only one connection is active at a time.
- You receive the SIM PIN code from your mobile network service provider together with the SIM card. If you enter the SIM PIN code incorrectly three times2) in a row, the SIM card will be be blocked. A PUK (personal unblocking key) must be entered in order to reactivate the SIM card.
- The Bluetooth connection between the system and the mobile phone is automatically terminated when you leave the car.
- For further information regarding your mobile phone, contact your mobile network service provider or refer to the operating instructions for your mobile phone. For information on using a phone in your car, please go online www.audi.com/bluetooth or ask an Audi dealer.
